| Model | TS-ABC500 | TS-ABC550 | TS-ABC600 |
| Screw diameter | ￠55x2 | ￠55x2 | ￠60x2 |
| Aspect ratio | 28:1 | 28:1 | 28:1 |
| Film folding diameter | 800 | 1000 | 1200 |
| Thickness of film on one side | 0.015-0.10 | 0.015-0.10 | 0.015-0.10 |
| Yield | 40 | 65 | 80 |
| Monitor rate | 11x2 | 15x2 | 18.5x2 |
| Heating power | 26 | 30 | 42 |
| Dimensions | 4200x2200x4000mm | 4600x2400x4600mm | 5000x2800x5000mm |
| Machine weight | 4T | 5T | 6T |
Optional Equipped
1. Automatic suction machine
2. Surface Treatment
3. Rotary die Head
4. The air compressor
5. Quick screen changer
Co-extrusion A+B+A combination film blowing machine, whether producing HDPE material or LDPEAnd LLDPE materials, have unique characteristics.
Improved thinning through multi-layer co-extrusionThe physical strength of the film can be reduced by one host by using one host for the inner and outer layers.configuration, and at the same time achieve the purpose of reducing costs, energy saving and low consumption.
