Product number |
TC-680B Intelligent Express Packing Machine |
TC-680A hot-selling high-speed express baling machine |
TC-680 high-speed express baling machine |
|
Bagging process |
scanning Print veneer sheet Pack Conveying is completed in one step |
Automatic order packaging Conveying is completed in one step |
Automatic bagging Packing and conveying Completed in one step |
|
Plastic bag specifications |
PE roll bag thickness: 0.04-0.08mm width: 200-550mm length 260-800m |
Thickness of rolled bag: 0.04-0.08mm Width: 200-550mm Length 250-800mm |
Thickness of rolled bag: 0.04-0.08mm Width: 200-550mm Length 250-800mm |
|
Packing speed |
950 bags/hour |
950 bags/hour |
950 bags/hour |
|
Order size |
Width: Max 100mm Length: 100, 180mm or freely set |
100*180mm, 76*130mm and other surface sheets used on the market can be used |
* |
|
Human-machine interface |
Mouse, touch screen, virtual keyboard |
* |
* |
|
Display |
15 inch LCD15 inch LCD |
7inch human-machine interface |
7inch human-machine interface |
|
External communication |
Ethernet, USB,RS232 |
* |
* |
|
Power |
1500W |
1500W |
1500W |
|
Power supply |
AC220V,50/60Hz |
AC220V,50/60Hz |
AC220V,50/60Hz |
|
Air pressure source |
0.07m/min 5kg/cm3 |
0.07m3/min 5kg/cm3 |
0.07m3/min 5kg/cm3 |
|
Machine size |
L1680*W850*H1420mm |
L1680*W850*H1420mm |
L1680*W850*H1420mm |
|
Plastic bag specifications |
PE roll bag film thickness: 0.04-0.08mm Width: 220-550mm Length: 260-800mm |
||
|
Order size |
Width: Maximum 100mm, no limit to length |
||
|
Packing speed |
About 1000 bags/hour |
||
|
Human-machine interface |
Mouse, touch screen, virtual keyboard |
||
|
Display |
12-inch LCD |
||
|
External communication |
Ethernet, USB, RS232 |
||
|
Air pressure source |
0.025m3/min, 5kg/cm3 |
||
|
Power supply |
AC220v, 50/60Hz, power 1500w |
||
|
Mechanical Dimensions |
Length 1580X Width 850X Height 1420mm |
||
|
Weight |
200kg |
||
