| Model | TS-B75 | TS-B100 |
| Screw diameter | ￠75 | ￠100 |
| Aspect ratio | 28:1 | 28:1 |
| Film folding diameter | 700-1500 | 1200-2000 |
| Thickness of film on one side | 0.008-0.10 | 0.008-0.10 |
| Yield | HD 70kg/hr LD 80kg/hr | HD 90kg/hr LD 100kg/hr |
| Monitor rate | 30-37kw | 45-55kw |
| Average power consumpxion | 40kw | 60kw |
| Dimensions | 6000x3000x7500mm | 7100x3500x9000mm |
| Machine weight | 4T | 5.5T |
1. Automatic duplex winder with automatic roll changing, cutting film, remember m power Energy.
2. Precision dual air suction air ring.
3. Rack surface using advanced paint process, looks nice, Long life, anti-rust performance outstanding.
4. IBC cooling device inside the bubble, not only to increase production, reduce energy consumption, but also Improve the quality of film products.
1. Two-tier co-extruded composite film can prolong the shelf life of liquid packaging.
2. Extruder barrel and screw are made of high quality alloy steel after nitrogen treatment and precision machining, Make optimum hardness and durability.
3. Auxiliary platform working table for making operation easy and is equipped to develop range.
4. Coiling device: double, double cut, which adopts torque motor to keep proper tension Winding neat,easy to change the volume.
