| Model | TS-QDF600 | TS-QDF800 | TS-QDF1000 |
| Composite width | 600mm | 800mm | 1000mm |
| Number of composite layers | 2layers | 2layers | 2layers |
| Compound speed | 10-120m/min | 10-120m/min | 10-120m/min |
| Roll diameter | ￠800mm | ￠800mm | ￠800mm |
| Oven temperature | 120C | 120C | 120C |
| Total power | 44Kw | 48Kw | 52Kw |
| Weight | 7500Kg | 8200Kg | 8900Kg |
| Dimensions | 9600X2400X3300mm | 9600X2650X3300mm | 9600X2850X3300mm |
1. Imported high precision T-Die.
2. Extruder; Automatically temperature control and material feeding.
3. Triplicate roller extrusion laminatbn device to ensure the quality and efficiency of machine.
4. Whole machine with fully automatic tension control.
1. T-Die it applies to high precision Hanger-type. Width of lamination is adjustable.
2. Triplicate roller extrusion lamination device to ensure the quality and efficiency of machine.
3. The whole machine is PLC computerized control.
4. Appear of new design structure, nice exterior, easy of installation as well as operation.
5. Extruder: Automatically temperature control and material feeding.
